Ariette
F0500009 Fabric

Ariette 2

Wall or ceiling-mounted lamp providing diffused light. Synthetic fabric diffuser. 30% fiberglass reinforced polyamide ceiling/wall fitting.

Halogen - 4 x 40W

Find a Flos store
Technical Drawing
ariette-2-ceiling-wall-scarpa-flos-F0500009-spech-tech-02-300x263
Main specifications
EAN
8059607014226
Mounting
Ceiling, Wall
Environments
Indoor dry location
Light source type
Bulb
Light sources included
No
Lamp category
Halogen
Lamp holders
E27
Ilcos
HSGSA
Number of lamps
4
Power (W)
40
Schematic light drawing
F0500009WARIETTE-2_4X40W-HL
Photometric
Light distribution
Symmetric
Extreme cut off
No
Electrical
Insulation class
II
Frequency (Hz)
50/60
Main voltage (Vac)
220-250
Dimmable
Yes
Dimming interface
Remote Dimmable (Dimmer Not Included)
Batteries inside
No
Physical
Colour
Fabric
Length (mm)
1000
Net weight (kg)
0.95
Package height (mm)
100
Package width (mm)
690
Package length (mm)
200
Package volume (m3)
0.01
IP internal
20
CE
CCC
EAC
CMIM
ENEC
IRAM
UKCA
IECEC
RETILAP

Download

Tech spec pdf
Mounting instructions

Photometric Files

LDT / IES

Technical Drawings

2D
3D

Bulbs

Spare Parts

F0500009-ariette2-flos-boom
01. Ariette 2 front & rear cloths. 100x100cm
RF06111
02. Ariette 1/2/3 fork push rod
RF0400100
03. Ariette 1/2/3 Lamp holder assembly
RF04635
04. Ariette 1/2/3 Rod nylon support/6 Ariette 1
RF05737
05. Ariette 2 fiberglass rod d.6 mm 6x670
RF05757
06. Ariette 1/2/3 Nylon wall attachment
RF05740
07. Ariette 1/2/3 Kit with grub screw & screws for rod support
RF0400200
