05.5415.40A WhiteMy Spot Ø25 Long Recessed
Designed by FLOS Architectural, 2024
LED lighting module for recessed applications. Optical with double focal lens technology, low glare and high visual comfort. Adjustable by tilting and turning. In the downlight position, the connector arm is perfectly flush with the product.
LED - Power LED - 2.5W - 216lm - 3000K - CRI> 90 - Beam° 11
Technical Drawing
Main specifications
Mounting
Recessed
Environments
Indoor dry location
Light source type
LED
Light sources included
Yes
LED type
Power LED
Lamp category
LED
Number of lamps
1
Power (W)
2.5
Source flux (lm)
326
Lumen Output (lm)
216
Schematic light drawing
Photometric
Lighting type
Direct
Light distribution
Symmetric
CCT (K)
3000
CRI>
90
Beam angle C0-180 (º)
11
Beam angle C90-270 (º)
11
Extreme cut off
No
UGRL
<10
Electrical
Insulation class
III
Forward voltage (V)
3
LED current (mA)
800
Power supply
Remote
Dimmable
Yes
Power supply type
Dimmable
Dimming interface
Remote Dimmable (Dimmer Not Included)
Batteries inside
No
Physical
Colour
White
Rotation (º)
360
Longitudinal tilting (°)
90
Net weight (kg)
0.42
IP internal
20
IP external
20
Non-replaceable light source
