Belvedere Spot F2

Designed by Antonio Citterio/assistant Toan Nguyen

Belvedere Spot pertenece a una familia de luminarias led orientables para exterior, aptas para su instalación en el suelo (sobre el pavimento o enterradas).

Download Documentation

Product highlight

Diseño sutil

Las lámparas se han concebido con gran acierto como camuflables en el exterior, como unos discretos artefactos.

Luminarias

(108)

Tipo de óptica

Flujo neto (lm)

CCT (K)

Regulable

Certifications

Color

Code	Name	Fuente de alimentación (W)	Flujo neto (lm)	CCT (K)	IRC>	Beam angle (º)	Dimming Type	Montaje
F001D43B033	Belvedere Spot F2 Dimmable 1-10V Anthracite	6	360	4000	80	28	Regulación 1-10 V	A tierra
F001D43B030	Belvedere Spot F2 Dimmable 1-10V Black	6	360	4000	80	28	Regulación 1-10 V	A tierra
F001D43B018	Belvedere Spot F2 Dimmable 1-10V Deep Brown	6	360	4000	80	28	Regulación 1-10 V	A tierra
F001D43B012	Belvedere Spot F2 Dimmable 1-10V Forest Green	6	360	4000	80	28	Regulación 1-10 V	A tierra
F001D43B006	Belvedere Spot F2 Dimmable 1-10V Grey	6	360	4000	80	28	Regulación 1-10 V	A tierra
F001D43B001	Belvedere Spot F2 Dimmable 1-10V White	6	360	4000	80	28	Regulación 1-10 V	A tierra
F001D43A033	Belvedere Spot F2 Non Dimmable Anthracite	6	360	4000	80	28	No dimable	A tierra
F001D43A030	Belvedere Spot F2 Non Dimmable Black	6	360	4000	80	28	No dimable	A tierra
F001D43A018	Belvedere Spot F2 Non Dimmable Deep Brown	6	360	4000	80	28	No dimable	A tierra
F001D43A012	Belvedere Spot F2 Non Dimmable Forest Green	6	360	4000	80	28	No dimable	A tierra
F001D43A006	Belvedere Spot F2 Non Dimmable Grey	6	360	4000	80	28	No dimable	A tierra
F001D43A001	Belvedere Spot F2 Non Dimmable White	6	360	4000	80	28	No dimable	A tierra
F001D42B033	Belvedere Spot F2 Dimmable 1-10V Anthracite	6	360	4000	80	17	Regulación 1-10 V	A tierra
F001D42B030	Belvedere Spot F2 Dimmable 1-10V Black	6	360	4000	80	17	Regulación 1-10 V	A tierra
F001D42B018	Belvedere Spot F2 Dimmable 1-10V Deep Brown	6	360	4000	80	17	Regulación 1-10 V	A tierra
F001D42B012	Belvedere Spot F2 Dimmable 1-10V Forest Green	6	360	4000	80	17	Regulación 1-10 V	A tierra
F001D42B006	Belvedere Spot F2 Dimmable 1-10V Grey	6	360	4000	80	17	Regulación 1-10 V	A tierra
F001D42B001	Belvedere Spot F2 Dimmable 1-10V White	6	360	4000	80	17	Regulación 1-10 V	A tierra
F001D42A033	Belvedere Spot F2 Non Dimmable Anthracite	6	360	4000	80	17	No dimable	A tierra
F001D42A030	Belvedere Spot F2 Non Dimmable Black	6	360	4000	80	17	No dimable	A tierra
F001D42A018	Belvedere Spot F2 Non Dimmable Deep Brown	6	360	4000	80	17	No dimable	A tierra
F001D42A012	Belvedere Spot F2 Non Dimmable Forest Green	6	360	4000	80	17	No dimable	A tierra
F001D42A006	Belvedere Spot F2 Non Dimmable Grey	6	360	4000	80	17	No dimable	A tierra
F001D42A001	Belvedere Spot F2 Non Dimmable White	6	360	4000	80	17	No dimable	A tierra
F001D41B033	Belvedere Spot F2 Dimmable 1-10V Anthracite	6	389	4000	80	10	Regulación 1-10 V	A tierra
F001D41B030	Belvedere Spot F2 Dimmable 1-10V Black	6	389	4000	80	10	Regulación 1-10 V	A tierra
F001D41B018	Belvedere Spot F2 Dimmable 1-10V Deep Brown	6	389	4000	80	10	Regulación 1-10 V	A tierra
F001D41B012	Belvedere Spot F2 Dimmable 1-10V Forest Green	6	389	4000	80	10	Regulación 1-10 V	A tierra
F001D41B006	Belvedere Spot F2 Dimmable 1-10V Grey	6	389	4000	80	10	Regulación 1-10 V	A tierra
F001D41B001	Belvedere Spot F2 Dimmable 1-10V White	6	389	4000	80	10	Regulación 1-10 V	A tierra
F001D41A033	Belvedere Spot F2 Non Dimmable Anthracite	6	389	4000	80	10	No dimable	A tierra
F001D41A030	Belvedere Spot F2 Non Dimmable Black	6	389	4000	80	10	No dimable	A tierra
F001D41A018	Belvedere Spot F2 Non Dimmable Deep Brown	6	389	4000	80	10	No dimable	A tierra
F001D41A012	Belvedere Spot F2 Non Dimmable Forest Green	6	389	4000	80	10	No dimable	A tierra
F001D41A006	Belvedere Spot F2 Non Dimmable Grey	6	389	4000	80	10	No dimable	A tierra
F001D41A001	Belvedere Spot F2 Non Dimmable White	6	389	4000	80	10	No dimable	A tierra
F001D33B033.A	Belvedere Spot F2 Dimmable 1-10V Anthracite	6	360	3000	80	28	Regulación 1-10 V	A tierra
F001D33B030.A	Belvedere Spot F2 Dimmable 1-10V Black	6	360	3000	80	28	Regulación 1-10 V	A tierra
F001D33B018.A	Belvedere Spot F2 Dimmable 1-10V Deep Brown	6	360	3000	80	28	Regulación 1-10 V	A tierra
F001D33B012.A	Belvedere Spot F2 Dimmable 1-10V Forest Green	6	360	3000	80	28	Regulación 1-10 V	A tierra
F001D33B006.A	Belvedere Spot F2 Dimmable 1-10V Grey	6	360	3000	80	28	Regulación 1-10 V	A tierra
F001D33B001.A	Belvedere Spot F2 Dimmable 1-10V White	6	360	3000	80	28	Regulación 1-10 V	A tierra
F001D33A033.A	Belvedere Spot F2 Non Dimmable Anthracite	6	360	3000	80	28	No dimable	A tierra
F001D33A030.A	Belvedere Spot F2 Non Dimmable Black	6	360	3000	80	28	No dimable	A tierra
F001D33A018.A	Belvedere Spot F2 Non Dimmable Deep Brown	6	360	3000	80	28	No dimable	A tierra
F001D33A012.A	Belvedere Spot F2 Non Dimmable Forest Green	6	360	3000	80	28	No dimable	A tierra
F001D33A006.A	Belvedere Spot F2 Non Dimmable Grey	6	360	3000	80	28	No dimable	A tierra
F001D33A001.A	Belvedere Spot F2 Non Dimmable White	6	360	3000	80	28	No dimable	A tierra
F001D32B033.A	Belvedere Spot F2 Dimmable 1-10V Anthracite	6	382	3000	80	17	Regulación 1-10 V	A tierra
F001D32B030.A	Belvedere Spot F2 Dimmable 1-10V Black	6	382	3000	80	17	Regulación 1-10 V	A tierra
F001D32B018.A	Belvedere Spot F2 Dimmable 1-10V Deep Brown	6	382	3000	80	17	Regulación 1-10 V	A tierra
F001D32B012.A	Belvedere Spot F2 Dimmable 1-10V Forest Green	6	382	3000	80	17	Regulación 1-10 V	A tierra
F001D32B006.A	Belvedere Spot F2 Dimmable 1-10V Grey	6	382	3000	80	17	Regulación 1-10 V	A tierra
F001D32B001.A	Belvedere Spot F2 Dimmable 1-10V White	6	382	3000	80	17	Regulación 1-10 V	A tierra
F001D32A033.A	Belvedere Spot F2 Non Dimmable Anthracite	6	382	3000	80	17	No dimable	A tierra
F001D32A030.A	Belvedere Spot F2 Non Dimmable Black	6	382	3000	80	17	No dimable	A tierra
F001D32A018.A	Belvedere Spot F2 Non Dimmable Deep Brown	6	382	3000	80	17	No dimable	A tierra
F001D32A012.A	Belvedere Spot F2 Non Dimmable Forest Green	6	382	3000	80	17	No dimable	A tierra
F001D32A006.A	Belvedere Spot F2 Non Dimmable Grey	6	382	3000	80	17	No dimable	A tierra
F001D32A001.A	Belvedere Spot F2 Non Dimmable White	6	382	3000	80	17	No dimable	A tierra
F001D31B033.A	Belvedere Spot F2 Dimmable 1-10V Anthracite	6	380	3000	80	10	Regulación 1-10 V	A tierra
F001D31B030.A	Belvedere Spot F2 Dimmable 1-10V Black	6	380	3000	80	10	Regulación 1-10 V	A tierra
F001D31B018.A	Belvedere Spot F2 Dimmable 1-10V Deep Brown	6	380	3000	80	10	Regulación 1-10 V	A tierra
F001D31B012.A	Belvedere Spot F2 Dimmable 1-10V Forest Green	6	380	3000	80	10	Regulación 1-10 V	A tierra
F001D31B006.A	Belvedere Spot F2 Dimmable 1-10V Grey	6	380	3000	80	10	Regulación 1-10 V	A tierra
F001D31B001.A	Belvedere Spot F2 Dimmable 1-10V White	6	380	3000	80	10	Regulación 1-10 V	A tierra
F001D31A033.A	Belvedere Spot F2 Non Dimmable Anthracite	6	380	3000	80	10	No dimable	A tierra
F001D31A030.A	Belvedere Spot F2 Non Dimmable Black	6	380	3000	80	10	No dimable	A tierra
F001D31A018.A	Belvedere Spot F2 Non Dimmable Deep Brown	6	380	3000	80	10	No dimable	A tierra
F001D31A012.A	Belvedere Spot F2 Non Dimmable Forest Green	6	380	3000	80	10	No dimable	A tierra
F001D31A006.A	Belvedere Spot F2 Non Dimmable Grey	6	380	3000	80	10	No dimable	A tierra
F001D31A001.A	Belvedere Spot F2 Non Dimmable White	6	380	3000	80	10	No dimable	A tierra
F001D23B033.A	Belvedere Spot F2 Dimmable 1-10V Anthracite	6	351	2700	80	28	Regulación 1-10 V	A tierra
F001D23B030.A	Belvedere Spot F2 Dimmable 1-10V Black	6	351	2700	80	28	Regulación 1-10 V	A tierra
F001D23B018.A	Belvedere Spot F2 Dimmable 1-10V Deep Brown	6	351	2700	80	28	Regulación 1-10 V	A tierra
F001D23B012.A	Belvedere Spot F2 Dimmable 1-10V Forest Green	6	351	2700	80	28	Regulación 1-10 V	A tierra
F001D23B006.A	Belvedere Spot F2 Dimmable 1-10V Grey	6	351	2700	80	28	Regulación 1-10 V	A tierra
F001D23B001.A	Belvedere Spot F2 Dimmable 1-10V White	6	351	2700	80	28	Regulación 1-10 V	A tierra
F001D23A033.A	Belvedere Spot F2 Non Dimmable Anthracite	6	351	2700	80	28	No dimable	A tierra
F001D23A030.A	Belvedere Spot F2 Non Dimmable Black	6	351	2700	80	28	No dimable	A tierra
F001D23A018.A	Belvedere Spot F2 Non Dimmable Deep Brown	6	351	2700	80	28	No dimable	A tierra
F001D23A012.A	Belvedere Spot F2 Non Dimmable Forest Green	6	351	2700	80	28	No dimable	A tierra
F001D23A006.A	Belvedere Spot F2 Non Dimmable Grey	6	351	2700	80	28	No dimable	A tierra
F001D23A001.A	Belvedere Spot F2 Non Dimmable White	6	351	2700	80	28	No dimable	A tierra
F001D22B033.A	Belvedere Spot F2 Dimmable 1-10V Anthracite	6	368	2700	80	17	Regulación 1-10 V	A tierra
F001D22B030.A	Belvedere Spot F2 Dimmable 1-10V Black	6	368	2700	80	17	Regulación 1-10 V	A tierra
F001D22B018.A	Belvedere Spot F2 Dimmable 1-10V Deep Brown	6	368	2700	80	17	Regulación 1-10 V	A tierra
F001D22B012.A	Belvedere Spot F2 Dimmable 1-10V Forest Green	6	368	2700	80	17	Regulación 1-10 V	A tierra
F001D22B006.A	Belvedere Spot F2 Dimmable 1-10V Grey	6	368	2700	80	17	Regulación 1-10 V	A tierra
F001D22B001.A	Belvedere Spot F2 Dimmable 1-10V White	6	368	2700	80	17	Regulación 1-10 V	A tierra
F001D22A033.A	Belvedere Spot F2 Non Dimmable Anthracite	6	368	2700	80	17	No dimable	A tierra
F001D22A030.A	Belvedere Spot F2 Non Dimmable Black	6	368	2700	80	17	No dimable	A tierra
F001D22A018.A	Belvedere Spot F2 Non Dimmable Deep Brown	6	368	2700	80	17	No dimable	A tierra
F001D22A012.A	Belvedere Spot F2 Non Dimmable Forest Green	6	368	2700	80	17	No dimable	A tierra
F001D22A006.A	Belvedere Spot F2 Non Dimmable Grey	6	368	2700	80	17	No dimable	A tierra
F001D22A001.A	Belvedere Spot F2 Non Dimmable White	6	368	2700	80	17	No dimable	A tierra
F001D21B033.A	Belvedere Spot F2 Dimmable 1-10V Anthracite	6	371	2700	80	10	Regulación 1-10 V	A tierra
F001D21B030.A	Belvedere Spot F2 Dimmable 1-10V Black	6	371	2700	80	10	Regulación 1-10 V	A tierra
F001D21B018.A	Belvedere Spot F2 Dimmable 1-10V Deep Brown	6	371	2700	80	10	Regulación 1-10 V	A tierra
F001D21B012.A	Belvedere Spot F2 Dimmable 1-10V Forest Green	6	371	2700	80	10	Regulación 1-10 V	A tierra
F001D21B006.A	Belvedere Spot F2 Dimmable 1-10V Grey	6	371	2700	80	10	Regulación 1-10 V	A tierra
F001D21B001.A	Belvedere Spot F2 Dimmable 1-10V White	6	371	2700	80	10	Regulación 1-10 V	A tierra
F001D21A033.A	Belvedere Spot F2 Non Dimmable Anthracite	6	371	2700	80	10	No dimable	A tierra
F001D21A030.A	Belvedere Spot F2 Non Dimmable Black	6	371	2700	80	10	No dimable	A tierra
F001D21A018.A	Belvedere Spot F2 Non Dimmable Deep Brown	6	371	2700	80	10	No dimable	A tierra
F001D21A012.A	Belvedere Spot F2 Non Dimmable Forest Green	6	371	2700	80	10	No dimable	A tierra
F001D21A006.A	Belvedere Spot F2 Non Dimmable Grey	6	371	2700	80	10	No dimable	A tierra
F001D21A001.A	Belvedere Spot F2 Non Dimmable White	6	371	2700	80	10	No dimable	A tierra
