Light Shadow
05.1117.14C90Black/BronzeLight Shadow Fixed Trim 4 Spots Optic Medium - Airtight IC Rated
Designed by FLOS Architectural
Recessed integrated luminaire with 4 LED lighting spots. Remote power supply included.
LED - Power LED - 10.8W - 1091lm - 3000K - CRI> 90 - Beam° 23
Technical Drawing
Main specifications
Mounting
Ceiling recessed
Environments
Indoor dry location
Light Source Type
LED
Light sources included
Yes
LED type
Power LED
Lamp category
LED
Number of lamps
1
Power (W)
10.8
System power (W)
10.8
Source flux (lm)
1272
System flux (lm)
1091
Efficacy (lm/W)
101
Schematic light drawing
Photometric
Lighting type
Direct
Light distribution
Symmetric
CCT (K)
3000
CRI>
90
LED Life / Failure Ratio
L80B50>50.000h (Tc=85ºC)
Beam angle C0-180 (º)
23
Beam angle C90-270 (º)
23
Extreme cut off
No
UGRL
<10
Electrical
Forward voltage (V)
12.9
LED current (mA)
900
Driver
Remote
Dimmable
Yes
Dimming interface
Remote Dimmable (Dimmer Not Included)
Physical
Color
Black/Bronze
Trim
Yes
Orientation
Fixed
Net weight (lb)
0.75
Gross weight (lb)
1.02
Package volume (in)
61.02
IP internal
20
Notes
Pre-Installation frame not required.
