Spine
F02504BAU30BlackSpine T 1 Absolute
Designed by Vincent Van Duysen, 2021
LED COB light source integrated. Integrated electric power supply ON/OFF. Integrated support for pole fixing, for poles with a diameter between 60 and 120 mm and a maximum thickness of 3 mm. Equipped with a 5 m neoprene cable (10 m upon request) for remote connection. To guarantee its water tightness, it is recommended to use flexible cables designed for outdoor use. Upon request: 1-10 V or DALI dimmable version with 24 Vdc remote power supply.
1011lm - 4000K - CRI> 80 - Beam° 15
Technical Drawing
Main specifications
EAN
8054793411200
Mounting
Pole Top
Environments
Outdoor wet location
Light Source Type
LED
Light sources included
Yes
LED type
Power LED
System power (W)
11
Source flux (lm)
1364
System flux (lm)
1011
Schematic light drawing
Photometric
Lighting type
Direct
Light distribution
Symmetric
CCT (K)
4000
CRI>
80
Beam angle C0-180 (º)
15
Beam angle C90-270 (º)
15
Extreme cut off
No
Electrical
Insulation class
I
Frequency (Hz)
50/60
Main voltage (Vac)
110-127
Driver
Integrated
Dimmable
No
Dimming type
Non Dimmable
Dimming interface
Not Dimmable
Physical
Color
Black
Orientation
Adjustable
Rotation (º)
360
Longitudinal tilting (°)
270
Cord length (in)
196.850
Net weight (lb)
1.98
Gross weight (lb)
2.87
Package height (in)
10.43
Package width (in)
11.42
Package length (in)
8.07
Package volume (in)
961.37
IP internal
66
IP external
66
Notes
5 m neoprene cable (10 m upon request) for remote connection.
