IC Lights
F3154059Brass

IC Lights T3

Table lamp emitting diffused light. Features an angled frame in brass, chrome-plated or black steel, paired with a blown opal glass diffuser. Dimmer switch located on the power cable. Available in three models.

LED retrofit - 25W

Find a Flos store
Also available in:
Technical Drawing
Flos-Pim-Technical_Drawing-Luminaire-Table-IC_Lights-T3
Main specifications
EAN
8059607068359
Mounting
Table
Environments
Indoor dry location
Light source type
Bulb
Light sources included
Yes
Lamp category
LED retrofit
Lamp holders
E27
Bulb finish
Opal
Number of lamps
1
Power (W)
25
Schematic light drawing
F31540XXWIC-T3_E27_25W-LED
Photometric
Lighting type
Direct, Indirect
Light distribution
Asymmetric
Electrical
Insulation class
I
Frequency (Hz)
50/60
Main voltage (Vac)
220-240
Dimmable
Yes
Dimming interface
Dimmer Integrated
Plug type
Type C
Batteries inside
No
Physical
Colour
Brass
Length (mm)
480
Cord colour
Black
Cord length (mm)
2000
Net weight (kg)
7.4
Package volume (m3)
0.22
IP internal
20
CE
EAC
ENEC
RETILAP
Autoprotected Lamp
20

Download

Tech spec pdf
Mounting instructions

Photometric Files

LDT / IES

Technical Drawings

2D
3D

Ecodesign and Energy Labelling

This product contains a light source of energy efficiency class D

Bulbs

x1
INCLUDEDLED 25W E27 3700lm 2700K 240° DIMMERRF36503

Spare Parts

F3154059-IC-T3-flos-boom
00. IC T3 Or ring
RF31770
01. Black Dimmer Switch
RF28206
02. IC T3 Lower brass leg
RF3154059
03. IC T/S 3 Fixed flange semi-cover for brass diffuser
RF36457
04. IC T/S 3 Kit of screws and allen key
RF3154100
05. IC 3 White/brass diffuser
F3153059
x1
IC T3 Or ringRF31770
x1
Black Dimmer SwitchRF28206
Thumbnail
x1
IC T3 Lower brass legRF3154059
Thumbnail
x1
IC T/S 3 Fixed flange semi-cover for brass diffuserRF36457
Thumbnail
x1
IC T/S 3 Kit of screws and allen keyRF3154100
Thumbnail
x1
IC 3 White/brass diffuserF3153059
